Max. capacity

5kN

Cantilever distance

80mm

Test stroke(w/o grip)

800 mm

Speed range

8~550 mm/min

Units

Force: gf, kgf, lbf, N, kN, ozf, tonf(SI), ton(long), tonf(short)
Stress: Kpa, Mpa, psi, bar, mm-Aq, mm-Hg
Length:m, cm, mm, ft, in

Force Resolution

23 bits

Force Precision

1/10,000

Stroke resolution

0.0125 mm

PC-Port

RJ45(TCP/IP)

Data sampling rate

1200Hz (Max.)

Motor type

DC Motor

Test Methods

Tensile, Compression, 3p bend, 180˚ peel

Analysis Data

Over 170

Real Time Data

Force Display/ Displacement Display/ Time Display/ Stress Display/ Strain Display (Selectable)

Test End

Automatic detection of breaking, and also automatic return can be select

Protection

1. Over load protection
2. Over stroke protection
3. Over time protection
4. Up/Down limit
5. Emergency Stop

Feature

1. Automatic reading of load cell feature information. ( Load cell can be calibrated without installed on machine)
2. Automatic reading of displacement sensor feature information. ( Displacement sensor can be calibrated without installed on machine)
3.Quick release controller for easy to do repair and replacement

Power Supply

Single phase 100~240VAC, 5A

Dimension of Machine

50 X 50 X 145

Weight of Machine

80kg
